OP 0082BL
METAL CASE REEL Ø8mm
CHARACTERISTICS
Model
Hose material
Hose length
Hose I.D.
Air Inlet/Outlet:
Working pressure:
Burst pressure:
Temperature
Outer casing material:
Carton size:
N.W. /G.W
This reel is made of high-quality materials and qualifi ed spare parts, driven and released by the swirled
spring, which can rewind the hose automatically. The length of air hose ranges from 0-9.5m, can be
180°swiveled, enlarge the range of usage. If fi tted with different kinds of brackets, it is convenient to be
installed for use in different places.
INSTALLATION
1. This reel is suitable for installing near source of air. For a large area, please place it in the center of a
yard or work area, and then you can enlarge its cover area freely. Also you can extend the hose to the
most convenient point in this area.
2. The mounting bracket can be installed to a brick wall. There are many alternative positions in which the
unit can be placed. The key point is subject to what is convenient for the user.
• The most appropriate position is to mount it on a wall or post horizontally. Approximately 1m
above the ground.
D1200103.010
PU
33 Feet
8*12mm
1/4 inch
120PSI
360PSI
0°C - 60°C
STEEL
31cmx12cmx33.5cm
3.5kg/4.0kg
USE
