2 Description
The heating cycle is electronically controlled either in a TIME MODE,
where the heating time is selected, or in a TEMP MODE where the
desired temperature is selected.
The heater can further be run on 20% capacity when small yokes are used
or when there is a risk for too quick heating of sensitive workpieces (e.g.
bearings with C1 or C2 clearance).
2.1

Components

The induction heater consists of a U-shaped iron core with a large induction
coil on one of its legs. The control electronics sits in a separate control box
on top of the heater.
The temperature is controlled by means of a magnetic probe.
© simatec ag Induction Heater IH 240 / IH 240-L 20
