1 Relay contacts for blind motor control
Direct push button control (COM connection)
2
12V supply
3
4 Velbus
5 Direct push button control (up and down)
6 Up indication LED
Down indication LED
7
Forwarding LED
8
9 Power LED
Reception LED
10
11 Down operation mode LED
Up operation mode LED
12
Termination
13
If the module is connected as the final device on the VELBUS, place the 'TERM' jumper. Remove the jumper in all other cases.
14 Address setting
Enter a unique address (from '00' to 'FE' except for 'B1', 'C1', 'D1', 'E1', 'F1' and 'FF') for each module
Switch-off setting
15
Manuel down operation
16
17 Manuel up operation
See also connection examples on page 22 & 23 !
