2.0 Connection box Infra ER 2600W

2.1 Connection diagrams

In the back of this technical manual you will find the connection diagrams for connecting one or more
connection boxes with a maximum of 3 Infra ER 2600W heaters per connection box, PinTherm Infra
Connect, Digital Clock Thermostat and/or Room Thermostat. EN
[1] Connection diagram for 1 connection box
[2] Connection diagram for 2 or more connection boxes
2.2 Dimensions Connection box Infra ER 2600W
The dimensions of the control box are 376 x 300 x 121 (h x w x d)
2.3 Technical information Infra ER 2600W, PinTherm Infra Connect, Digital Clock Thermostat
or Room Thermostat.
For the installation, connection and / or maintenance of the electric radiant heaters and / or the
thermostats, please refer to the technical books supplied with these products. The technical manuals can
also be found on www.markclimate.com
3
