VIEW OF TYPICAL AUTOMATION AND NAMES OF COMPONENTS

5
Optimal installation
1- Motor with on-board electronics
2- External photocell
3- Flashing warning light
4- Antenna

TECHNICAL DATA

Max. weight of gate
Motors power supply
Motor current input
Motor power
Motor RPM
Condenser
Mechanical unlock for emergency manoeuvre
Working temperature
Weight
Protection rating
Opening time
Limit switch
7
2
6
8
3
5
1
5- Internal photocell
6- Rack
7- Key-switch
8- Remote control
230V
600 Kg
230 Vac
1.3 A
250 W
1400
12,5 µF
10 mt min
4
24V
350 / 600 Kg
24 Vdc
50 W
2000
With key
-20° C / +55° C
8 Kg
IP 44
12mt min
Electromechanical
5
3 A
1800
Encoder
/
