Samsung QE65QN95AATXXC Instructions De Réparation page 33

„ FUNCTION/IR/BT/WIFI Connecter
Circuit
1 A3.3V_PW_Sensor
5 DMIC_DATA
Pin
9
carte
13 A5V_PW_WiFi
17
21 WIFI_USB_ON
CN151_CM (FUNCTION & IR&BT/WIFI)
2
6
KEY1 10
14 A5V_PW_WiFi
GND 18
22
IR_OUT2 3
DMIC_CLK 7
I2C_SDA 11
15
BT_WAKE 19
GND 23
IR_OUT1 4
MIC_On/off 8
I2C_SCL 12
USB_D+ 16
BTWIFI_NRESET 20
BT_UART_TXD 24
Guide de réparation
GND
GND(KEY2)
LED
USB_D-
WIFI_WOW
IR
33
