TURNING THE E-SCOOTER ON/OFF:
•
Long press the power button (B) to turn on the E-Scooter. The LCD screen will light up.
•
Long press the power button (B) to turn off the E-Scooter. The LCD screen will turn off.
TURNING THE LIGHTS ON/OFF
•
Long press the button (C) to (de)activate the light.
•
The brake light will light always when you use the brake. The scooter is also equipped with
reflection or reflectors at the front, sides and rear.
STARTING TO RIDE
•
Slide the scooter with your foot for 1-2 meters and then press the accelerator (D) for driving.
•
Release the accelerator (D) and use the brake (2) for braking. When you need to brake very
suddenly, use the rear fender (8) to stop immediately.
Important: Braking distance will extend during wet weather.
•
To change directions, lean slightly to the left or right and turn the handlebars slightly.
•
When the screen is on, press the and buttons (A-C) to adjust the speed according to 1st,
2nd and 3rd class.
1st class
max. speed up to 6 km/h (pedestrian mode)
2nd class
max. speed up to 15 km/h
3rd class
max. speed up to 25 km/h
•
Please use the kickstand to keep your E-Scooter upright while parked or not in use.
BELL
The Guardo Swift 200 has a mechanical bell, you can ring to alert and warn the traffic around you.
SCREEN INFORMATION
SPECIFICATIONS
•
Max. continuous rated power: 250 W
•
Max load: 100 kg
•
Min. height of user: 130 cm
•
Suitable age: 14+
•
The A-weighted emission sound pressure level at workstations, is less than 70dB(A)
•
The peak C-weighted instantaneous sound pressure value at workstations, is less than 63Pa
•
The A-weighted sound power level emitted by the machinery, is less than 80dB(A)
1.
Selected speed class
2.
Odometer: total riding distance
3.
Actual speed
4.
Battery status
-7-
