Operation Basics

Hardware Overview

Visual alarm indicator
IrDA (infrared data
exchange) window
Sensor port 1 and dust
filter
On-off-mode button
LCD (liquid crystal
display)
Power on
Press for approximately three seconds to power on the unit. The instrument operator will see several start-up screens
(examples shown below) as the unit completes its start-up diagnostics. If the unit passes all diagnostic tests, the gas-monitoring
screen will be activated and the unit will be in operation mode. If any test fails, the unit will display an error code (see "Alarms"
and "Warnings" or refer to the Product Manual).
All manuals and user guides at all-guides.com
Visual alarm indicators
Sensor port 2 and dust filter
Enter button
Audible alarm indicator and
dust filter
2
Garment clip (open)
Garment clip (closed)
