Nature Power 500 Manuel Utilisateur page 5

1. Before the Solar Motion Light can operate to its full capacity, allow the unit to charge in sunlight
for 2 days with the solar panel wire connected to the light. Charging should be done with the unit
in the "OFF" position.
2. Located at the bottom of the Battery Housing there is a OFF/AUTO/ON switch:
"AUTO" position, the light will turn on automatically when motion is detected.
"ON" position, the light can be used as a standard light for constant illumination.
"OFF" position, the light will remain off and will not detect any movement.
How to Use Control Dials
The Solar Motion Light has 3 dials which control the light's duration,
sensitivity to light, and sensitivity to motion.
LUX (Light Level)
The LUX dial adjusts the sensitivity to darkness. If set to the maximum
level, the light will go on in daylight. If set to the minimum
the sensor will only trigger the light to turn on at dusk or when it is dark
out. This is the ideal position for general use. Please note that ambient
light will affect the sensor.
Time
The time dial sets the duration the light will stay on when triggered. The duration is adjustable from 8
seconds to 2 minutes. Rotating the dial clockwise will increase the duration the light will stay on.
SENS (Sensitivity)
The SENS dial adjusts the sensitivity of motion
detection:
1. Minimum position – Low Range: large movement
is required to trigger the light to turn on.
2. Mid Position - Medium setting.
3. Maximum position - Maximum range: the smaller movements will trigger the light to turn on.
Location of the Solar Light
Solar powered lights require sunlight to recharge the internal batteries. For best results, locate the
Solar Panel in a position where it will receive direct sunlight, and is generally free from cover and
shade.
Operating Instructions
Page 5 of 16
