WEIGHING
Place the scale on a flat and solid surface. Avoid carpet or soft surface. Press the ON/OFF button (4) to turn on the scale. Wait until the
scale displays the 0.00 value and the zero symbol on the lower left corner. Place the object to be weighed in the center on the surface of
the scale (1). Wait a moment for the result to stabilize.
TARE FUNCTION:
You can weigh different loads without removing them from the scale. Wait until display shows 0.00 value and zero symbol appears on the
lower left corner. Put first load on the scale, wait for weigh reading. Press Z/T button (5) to reset the LCD reading to 0.00 before adding next
load. You can repeat this operation.
When total sum of all loads on scale >4% (4gram) of scale's max capacity TARE function can sum total weigh of all loads on the scale.
Wait until display shows 0.00 value and zero symbol appears on the lower left corner. Put heavier than 4g load on the scale. Wait for weigh
reading. Press Z/T button (5) to reset the LCD reading to 0.00. Put next load on the scale. Press Z/T button (5) scale will sum the load and
show total weight of the load.
Press again Z/T button to reset the LCD reading to 0.00 before adding next load. You can repeat this operation.
PIECE COUNTING MODE
1. Press UNIT to select piece counting mode 'PCS' when the scale is vacant.
2. Press UNIT for 3 seconds to select pre-set quantity value either 25, 50 or 100. Choose quantity by pressing UNIT button. Example:
choose 50pcs. LCD will show 50, then place same quantity (50 pcs) on the scale surface. Wait for LCD to flash '50' a few times. Scale now
recognizes weight of 50 pcs. Also calculates and memorizes the average single unit weight value.
3. Next time weighing same object of different quantity. Turn on the scale, place X quantity of the object onto weighing platform. LCD will
show the weight as normal, then press 'UNIT' to piece counting mode 'PCS', LCD will display the quantity placed on the platform.
Remark: For calibration accuracy, pre-set quantity of 100 pcs is suggested. The object with unit weight less than 1 scale division can't be
calibrated.
REPLACING THE BATTERY (Fig. 2)
Remove the lid of the battery compartment at the bottom of the scale. Remove the old battery. Insert the new battery of the right type.
Close the lid of the battery compartment.

CLEANING AND MAINTENANCE

– Gently wipe the scale with a dry or slightly damp cloth.
MESSAGES
a – excessive scale load
b – low battery

TECHNICAL DATA

Auto shut off: 2min
Backlight auto shut off: 30sec
Capacity: 100g /3,5oz/64dwt/3ozt
Accuracy: d= 0,01g/0,0005oz/0,01dwt/0,0005ozt
Power: 2 x 3V battery (CR2032)
To protect your environment: please separate carton boxes and plastic bags and dispose them in corresponding waste bins.
Used appliance should be delivered to the dedicated collecting points due to hazarsous components, which may effect the
environment. Do not dispose this appliance in the common waste bin.
