Danfoss PVG 32 Guide D'installation page 4

Proportional Valve Group PVG 32
PVG - Standard mounting
PVEO
PVEA/PVEM
PVEH/PVES
PVG - Option mounting
Flow P
B
Max. ow: P B
6±1Nm[53±9lbf-in]
Max. ow: P A
6±1Nm[53±9lbf-in]
4
PVMR/PVMF
PVMD
PVH
B A
PVM
PVP
AN00000350xx-04 • Rev 0102 • Mar 2017
Oliestrommens retning og indstilling af max. oliestrøm.
Oil flow direction and setting of max. flow.
Richtung des Olatroms und Einstellung des max. Olstroms.
Sens du debit et reglage de debit maxi.
B A
PVBZ
PVB
PVP
Oliestrommens retning og indstilling af max. oliestrøm.
Oil flow direction and setting of max. flow.
Richtung des Olatroms und Einstellung des max. Olstroms.
Sens du debit et reglage de debit maxi.
PVS
PVBZ
PVB
PVEA/PVEM
PVEH/PVES
PVS
Flow P
Max. ow: P
6±1Nm[53±9lbf-in]
Max. ow: P
6±1Nm[53±9lbf-in]
PVM
PVMR/PVMF
PVMD
PVH
PVEO
P109137
© Danfoss A/S, 2017-03
A
B
A
P109136
