CARACTÉRISTIQUES TECHNIQUES

15.1. CORE

Inputs
Input Sensitivity* / Nominal Impedance
Input Sélecteur (same selection for Ch1&2)
Frequency Response (at TX AUX OUT)
THD+D (at TX AUX OUT)
Signal Noise Ratio (at TX AUX OUT)
Local Output
Nominal Output Level / Min Load
WiSpeak Channels (RF Wireless Audio)
General Controls (affects Ch1&2)
Tone Control (independent for each Ch)
3
High Pass Filter (independent for each Ch)
3
Low Pass Filter (independent for each Ch)
3
Type IN1: Balanced, Stereo, Euroblock
IN2: Unbalanced, Stereo, RCA
BT: Bluetooth wireless
IN1: -10dBV to 0dBV / >20kΩ
IN2: -10dBV to 0dBV / >20kΩ
BT: -10dBV FS
Gain Control Range IN 1&2: 10dB
2
Frontal panel keys /
WiSpeak grip control app
CMRR IN2: >60dB @ 1kHz
Bluetooth Input Type: Compliant 5.0, Class 1
Range: 25m (ideal conditions)
Profiles: A2DP1.3/AVRCP1.6/HFP1.6/HSP1.2
Decoder support: SBC, AAC
IN1: 10Hz – 20kHz (-1dB)
IN2: 10Hz – 20kHz (-1dB)
BT: 10Hz – 20kHz (-1dB)
IN 1&2: <0.015%
IN 1&2: >95dB
Type AUX OUT: Analog, Mono, Balanced, Euroblock
Input Selection CH 1&2: WiSpeak grip control app
AUX OUT: 0dBV / 10kΩ
Channel CH 1&2: Digital, Mono, RF Wireless Audio
Master VOL, MUTE: Frontal panel keys /
WiSpeak grip control app
BASS: 100Hz, ±10dB
MID: 1k2kHz, ±10dB
TREBLE: 10kHz, ±10dB
OFF / 120Hz / 150Hz
Butterworth 12dB/oct
OFF / 120Hz / 150Hz
Butterworth 12dB/oct
