Linear Technologie LINEARLEDS LTL.BL154 Manuel D'utilisation page 9

17 canaux
Canaux
1. LED
2. LED
3. LED
4. LED
5. LED
6. LED
7. LED
8. LED
9. LED
10. LED
11. LED
12. LED
13. LED
14. LED
15. LED
16. Strobe
17. Fade
11 canaux
Canaux
1. Dimming
2. Red
3. Green
4. Blue
5. White
6. Macro color control
7. Strobe
8. Module selection
9
Valeur
000 ~015
016 ~031
032 ~047
048 ~063
064 ~079
080 ~095
096 ~111
112 ~127
128 ~143
144 ~159
160 ~175
176 ~191
192 ~207
208 ~223
224 ~239
240 ~255
000 ~255
000 ~255
Valeur
000~255
000~255
000~255
000~255
000~255
000~009
010~255
000~255
000~004
005~034
035~064
065~094
095~124
125~154
155~184
185~214
215~244
245~255
Description
No function
R
G
B
R+G
G+B
R+B
R+G+B
W
R+W
G+W
B+W
R+G+W
G+B+W
R+B+W
R+G+B+W
Strobe (0~20HZ)
Dimmer speed (fast to slow)
Description
0-100%
0-100%
0-100%
0-100%
0-100%
No function
Macro color control
Strobe (00~20Hz)
#1=ON, #2=ON, #3=ON,
#1=ON
#2=ON
#3=ON
#1=ON, #2=ON
#1=ON, #3=ON
#2=ON, #3=ON
#1=ON, #2=ON, #3=ON ,
#1=OFF, #2=OFF, #3=OFF,
Convert to 11CH-2
