Intended Use - MW TOOLS POAD12 Mode D'emploi

TOOLS
1 Safety
WARNING!
Fire and explosion hazard.
Les pictogrammes
Installation site must be well vented and free of all flammable materials from area.
de sécurité
DANGER!
Les signaux d'avertissement
Reduce the risk of electric shock.
Disconnect power from the system before working on the unit to avoid personal injury, damage to the surrounding
environment and/or damage to the unit.
CAUTION!
Burn hazard.
Motor case could get hot during extended operation. Prolonged contact with skin may cause a burn.
2 Specifications
Model
Pump design
Motor design
Voltage
Motor rating
AMP draw
Fuse size
Pump body
Maximum flow rate
Maximum pressure
Liquid temperature
Duty cycle
Inlet/outlet fitting
Net weight

3 Intended use

The 5 chambers high flow pump is self-priming and can run dry without harm. It is intended for intermittent duty cycle
but can be run continuously for short periods of time. The higher duty cycle, the shorter the expected life of the pump.
Typical uses include transfer, delivery, spraying, cooling filtration, dispensing and pressure boosting.
4 Mounting
The pump is self-priming and may be located above or below the liquid supply in a dry location. To vertically mount the
unit, it is best to do so with the motor on top. This will prevent liquid dripping on the motor in the event of a leak. Place
the pump on a solid surface and secure with four mounting screws. Be careful not to compress the rubber grommets,
which are as vibration dampers.
POAD12
5 chambers diaphragm
Permanent magnet DC
17
12 V
IP54
16 amps @ 25 psi
35 A
Glass filled nylon
40 l/min
40 psi / 2.8 bar
5 ~ 60 °C
Continuous with self-ventilation
3/4'' HB ST
5.5 kg
POAD24
24 V
8 amps @ 25 psi
24 A
6
POAD12 - POAD24 - NLFREN - v1.0 - 20042017
EN
