Installation manual e-MatriX linear 1050-1300/400 I,II,III
A = EA Non-return valve
B = ½ or ¾ "connector
C = ¼ "1m pipe
D = valve
E = To be cut from a ¼ pipe length
of 1 meter
6.0
35 < < < <
F = Coarse filter
G = Fine filter
H = Control box
I = ¼ "1.5m pipe
J = Engine e-MatriX linear
5.0
7.0a 7.0b
1 = Safety clip (11x)
2 = Brackets (2x) fine filter
3 = Knee (4x)
7.0c 7.0d
