HID® Signo™ Reader
13.56 MHZ/125 kHz/2.4 GHz Contactless and Keypad Readers
SRD Models: 20, 20K, 40, 40K
Installation Guide
Supplied parts
ƒ HID Signo Reader (1)
ƒ Installation Guide (1)
ƒ Flat head/countersunk 0.138-20 x 1.5" self–tapping
screws (2) – for installing the reader directly to a wall
(no junction box)
ƒ Flat head/countersunk 0.138-32 x 0.375" machine
screws (3) – for Imperial (US) junction box installation
(2) and attaching the reader to the mounting plate (1)
ƒ Flat head/countersunk M3.5 x 12mm machine screws
(2) – for Metric (EU etc) junction box installation
ƒ Flat head/countersunk 0.138-32 x 0.375" security screw
(1) – alternative anti-tamper screw for attaching the
reader to the mounting plate
ƒ 5-pin terminal connectors, terminal strip models only (2)
Specifications
INPUT VOLTAGE (V DC)
CURRENT
STANDBY AVG
1
MAX AVG
2
PEAK
3
OPERATING TEMPERATURE
CABLE LENGTH
REGULATORY REF NUMBER
FREQUENCY
FCC IDS
IC IDS
1 Standby AVG - RMS current draw without a card in the RF field.
2 Maximum AVG - RMS current draw during continuous card reads. Not evaluated by UL.
3 Peak - highest instantaneous current draw during RF communication.
© 2019 - 2020 HID Global Corporation/ASSA ABLOY AB. All rights reserved. HID, the HID Brick logo, the Chain Design, HID Signo, HID Reader Manager, iCLASS,
and HID Mobile Access are trademarks or registered trademarks of HID Global, ASSA ABLOY AB, or its affiliate(s) in the US and other countries and may not be
used without permission. All other trademarks, service marks, and product or service names are trademarks or registered trademarks of their respective owners.
hi dg l o b a l.com
20
60 mA
70 mA
250 mA
-30° F to 150° F (-35° C to 66° C)
Wiegand = 500 ft - 18 AWG (152 m)
RS-485 = Max bus length: 4,000 ft - 24 AWG (1,219 m)
Max length between nodes: 1,640 ft - 24 AWG (500m)
20
BLE: 2.4–2.480 GHz, HF: 13.56 MHz, LF: 125 kHz
JQ6-SIGNO20 JQ6-SIGNO20K
2236B-SIGNO20 2236B-SIGNO20K
An ASSA ABLOY Group brand
Recommended parts
(not supplied)
ƒ Cable, 5-10 conductor (Wiegand or Clock-and-Data),
4 conductor Twisted Pair Over-All Shield and UL
approved, Belden 3107A or equivalent (OSDP)
ƒ Certified LPS DC power supply
ƒ Metal or plastic junction box
ƒ Security tool HID 04-0001-03 (for anti-tamper screw)
ƒ Drill with various bits for mounting hardware
ƒ Mounting hardware
ƒ Reader spacer when mounting on or near metal
or metal junction boxes. Refer to the Reader and
Credentials How to Order Guide (PLT-02630) for
available options and part numbers
ƒ Junction box
20K 40
12V DC
65 mA 65 mA
75 mA 75 mA
250 mA 250 mA
Communication Lines
300 ft - 20 AWG (91 m)
20K 40
JQ6-SIGNO40
2236B-SIGNO40
PLT-03704, Rev. A.3
40K
70 mA
80 mA
250 mA
40K
JQ6-SIGNO40K
2236B-SIGNO40K
