3. Start the rotation: press 9.A.2.
The real-time torque bar is displayed.
4. Stop the rotation: press the main switch 9.A.2.
The standby screen is displayed.
• Make sure the device is functioning properly before using it in mouth.
• Change the file on time to avoid file separation within the canal. File separation may occur due to
cyclic / torsional fatigue.
• Heavy force / hand pressure on the endo motor while using it may cause a file separation.
• Do not press the button to release the file while the motor is running, otherwise the file may come
off and hurt the patient.
• Electromagnetic noise in surroundings environment may interfere with the device operation
and may compromise the automatic control of the device. Always check that the display is not
disturbed.
• In case of dysfunction, stop using the device and report the issue to your after-sales service.
• Speed increases the risk of a file separation. Please follow the manufacturer's recommendations
regarding the speed and check the motor settings before use.
• Use Ni-Ti or stainless steel-made files only.
• Put a silicon cover onto the contra-angle before each use and especially when combined with
Dual Pex.
• Do not forget to remove the file from the contra-angle after use.

9. 3. General settings: speed, reverse torque, rotating direction, angles for M0 (Fig. 9.E)

Select the memory (program) with < / > keys then the parameter to be set.
9.E.1 Standby interface continuous mode
9.E.2
Speed setting
9.E.3 Reverse torque setting
9.E.4
Direction setting
1 - Touch < / > (- / +) to choose a memory number
2 - Touch the S key to select the parameter to be set
3 - Touch < / > (- / +) to adjust the parameter
M1 ... M6 Continuous rotation
M0* (op-
Reciprocation*
tional)
*M0 Reciprocation mode is only available when specified on the box
At each change, the new parameters are saved automatically. Automatic switch to the standby screen if no action
for a while (time-out to be set, factory value 5 seconds).
9.E.5
9.E.6
9.E.7
Rotation speed 120, 150, 200, 250, 300, 350, 400, 450, 500, 550, 600, 650 rpm
Rotation direction Fw: Forward (clockwise rotation)
Rev: Reverse (counter clockwise rotation)
Reverse torque RT 0.5, 0.8, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0 N.cm
If the effort applied to the file reaches 70% of RT: discontinuous audible alarm.
If the torque exceeds RT: continuous alarm, the auto-reverse is activated to disengage the file.
When the torque becomes again less than RT, then the device automatically restarts.
Forward :0°, 30°, 50°, 90°,150°, 170°, 210°, 250°
Reverse: 0°, 30°, 50°, 90°, 150°, 170°, 210°, 250°
Standby interface of M0 mode*
Forward angle setting for M0*
Reverse angle setting for M0*
