PASSLOCK-SL2
Copyright © 2006, FORTIN AUTO RADIO INC - ALL RIGHTS RESERVED
BYPASS MODULE FOR PASSLOCK I AND PASSLOCK II, SATURN, HUMMER H2, VATS AND NEW GENERATION
WIRING / CONNECTION GUIDE
LED
START HERE
Make the connections of the PASSLOCK-SL2
1
to the vehicle:
Connector 1 (Black):
1.A
Determine the type of installation:
INSTALLATION WITH
INSTALLATION WITHOUT DATA-LINK (See plan 2, Below).
Connector 2 (White):
(I) Locate the wiring type for the vehicle on the
1.B
VEHICLE FIT GUIDE (P.3)
(II) Make the connections associated with the vehicle in the
WIRING SCHEMATIC CONFIGURATION (P.3)
2
3
4
INSTALLATION WITH DATA-LINK
Plan 1
In Data-Link mode the
analog Inputs (Unlock,
ground out) are disable
for security.
TECHNICAL SUPPORT / INFORMATION
Neither the manufacturer or distributor of this module is responsible of
damages of any kind indirectly or directly caused by this module, except
for the replacement of this module in case of manufacturing defects. This
module must be install by qualified technician. This instruction guide may
change without notice. Visit www.ifar.ca to get latest version.
Green
2
Blue (-) While running
Orange/Black
Orange
Purple/White
Purple
Yellow/Black
Starter or accessory
Yellow Ignition or accessory
1
Red
Black
Blue
White
INSTALLATION AND PROGRAMMATION INSTRUCTIONS
DATA-LINK (See plan 1, Below).
Press and hold the programming
button. Plug the connector 2
(white) into the PASSLOCK-SL2
interface.
Plug in the connector 1
(black) on the PASSLOCK-SL2
interface.
The LED will turn on, indicating
the beginning of programming.
Starter or alarm
Data Link Port
2
1
Ground (-)
Data In Barillet
Data from BCM
Bulb test Out
Key sense Out
12V Batterie (+)
N.C.
Data-Link
Data-Link
5
6
7
You have 4 seconds to:
8
9
10
INSTALLATION WITHOUT DATA-LINK INSTALLATION WITHOUT DATA-LINK
Plan 2
Cut off one plug of
the Data-Link
connector, connect
the red wire to +12V
and the green wire to
ground.
Technical support:
TEL: 514-255-HELP (4357)
FAX: 514-255-1367
Web: www.ifar.ca
INSTALLATION GUIDE
Made in Canada - Rev. P - 05 / 12 / 2008
W e b s i t e : h t t p : / / w w w . i f a r . c a
See wiring schematic configuration
Connect wire to Remote-
Connect wire to
Starter/Alarm
vehicle
OUTPUT
INPUT
Release the programming button.
Turn the key to the ignition
position.
The LED will flash rapidly.
Start the vehicle with the key.
The LED will flash (1-6 times).
Turn the key OFF.
THE PASSLOCK-SL2 IS
PROGRAMMED.
Starter or alarm
2
Red +12V
1
7 7 0 3 5 0 0 0 1 4 9
