4.8. TECHNICAL DATA

4.8.1.

Device data

Weight
Material
Condensate connector
Supply voltage
Input power
Air volume flow rate DIBt
Air volume flow rate passive house
Sound level room ventilation unit (L
Sound level duct (L )
PA
Ambient temperature in the room where
the unit is installed
Outside air temperature (frost protection)
Maximum air humidity
Rotational speed control
DC ventilators
Cross-counter-current heat exchanger
Connection outside and outgoing air lines
Filter
Remote control
Programming
Heat supply rate according to DIBt approval
Air volume flow rate bypass (accessory)
Protection rating
26
OII Avent P190/P310/P460
AP190
(140 m³/h at 100 Pa)
50-180 m³/h
70-140 m³/h
) 52 dB(A)
PA
(140 m³/h at 100 Pa)
56 dB(A)
(140 m³/h at 100 Pa)
10 preset weekly programmes or one freely selectable weekly
AP310
37 kg 50 kg
Steel sheet painted white
¾" hose
230 V AV, 50 Hz
Schuko plug
51 W 62 W
(230 m³/h at 100 Pa)
70-300 m³/h
90-230 m³/h
53 dB(A)
(230 m³/h at 100 Pa)
58 dB(A)
(230 m³/h at 100 Pa)
+ 12 °C to +40 °C
to -20 °C
10 g/cm³
Can be preset at 4 levels
2 pieces, EC centrifugal fan radial backwards curved
Aluminium
Pluggit IPP46
Filter quality G4 (supply and exhaust air)
optionally filter quality F7 (outside air)
optional accessories
programme (automatic programme)
84,7 85,4
95 %
IP21
AP460
70 kg
96 W
(350 m³/h at 100 Pa)
120-450 m³/h
120-350 m³/h
55 dB(A)
(350 m³/h at 100 Pa)
60 dB(A)
(350 m³/h at 100 Pa)
85,7
±
5
