BAYLED RIGEL RGB 28-54W Instructions De Montage page 2

RIGEL RGB
ALTERNATIVE CONNECTION DIAGRAM-2
GND(signal)
IP68
3 Connector
D+
4 2
L
5 1
6
D-
N
(1 x twisted pair + 1 shield / ground)
GND(power)
120-277V AC (3 wire)
IP68 Connector
*The signal cables must be connected color to color or (number to number ) otherwise the product led colors will work asynchronous.
DMX 512 / RDM
IP68 T Connector
(1 x twisted pair + 1 shield / ground)
No more than
20 fixtures on a
single DMX 512 link,
max. 100 m total
(source to last fixture)
You can connect
multiple fixtures
power cable
(220 V AC)
power cable
(220 V AC)
DMX 512 / RDM
120-277V AC (3 wire)
PC
DMX
Controller
DMX splitter
G
Signal Cable
Connection Detail
( L )
( G )
Power Cable Detail
Line can be continue...
Data cabling from DMX source
to first fixture and between
subsequent Rigel fixtures shall
be Cat5e UTP or higher
(stranded type only) or other
cable type suitable for DMX
communication. Consult DMX
standard for additional
guidance.
Wago 221-413
D- D+
or equivalent
( N )
