REAR PANEL
Made in Europe (Fr)
230V
50/60Hz 12W
T 250mA L
N
A)
3 pins female XLR left channel ORDER input connector.
B)
3 pins female XLR right channel ORDER input connector.
ORDER input can be set to line or microphone level, according to JP1/JP2 (right) and
JP2/JP4 (left) position as follow:
LINE ORDER Input:
MICRO ORDER Input :
C)
Manual / Auto mode programming connector:
(Sub-D 9 female)
D)
Left A Input
E)
Right A Input
F)
Left B Input
G)
Right B Input
H)
Left C Input
I)
Right C Input
J)
Left D Input
K)
Right D Input
ENGLISH
PUSH
VCA IN
REMOTE
PHONES OUT
R
M
L
K
JP3
JP1
JP2
JP4
JP3
JP1
JP2
JP4
All the inputs are on
female XLR 3 pts.
PUSH
PUSH
PUSH
PUSH
L
R
L
R
INPUT D
INPUT C
J
I
H
G
JP3
JP1
JP2
JP4
Mode auto/manual right setting ( loop = manual )
Manual right loop ( loop = fade + order allowance )
Manual left loop ( loop = fade + order allowance )
Mode auto/manual left setting ( loop = manual )
14
PUSH
PUSH
PUSH
LOOP ORDER
L
R
L
INPUT B
INPUT A
F
E
D
PUSH
1
2
3
AMC 502
PUSH
PUSH
R
L
INPUT ORDER
C
B
A
+
+
+
+
1: Earth
2: Signal +
3: Signal -
