• Operating Instructions • Warning Information
S P E C I F I C A T I O N S
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Max. Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22,000 RPM
Collet Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4"
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4" NPT
Mim. Air Hose Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8" ID
Average Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 CFM
Recommended Air Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90 PSI
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.34"
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.85 LBS.
Sound Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 dBA
• MAxiMuM rpM of 22,000
• MAx Air preSSure:
90 pSig, 6.2 bAr
• rpM of The ACCeSSorY
MuST exCeed TooL rpM
ALwAYS reAd
inSTruCTionS
before uSing
power TooLS
ALwAYS weAr
SAfeTY goggLeS
weAr heAring
proTeCTion
Avoid
proLonged
expoSure To
vibrATion
MT2880
• Parts Breakdown
Some dust created by power sanding, sawing, grinding, drilling, and other construction
activities contains chemicals known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.
.MT2880
Copyright © Professional Tool Products, 2007

MT2880
.50 HP Straight
Die Grinder
All rights reserved.
rev. 08/0/07

Publicité

Table des Matières
loading

Sommaire des Matières pour Matco Tools MT2880

  • Page 5: Spécifications

    SPÉC IFI CATI O NS MT2880 Vitesse Max. à vide ........22 000 R/MIN Dimension de la pince .
  • Page 6: Utilisation

    MT2880 Rectifieuse Droite .50 CV le non-respecT de ces aVerTisseMenTs pourraiT enTraÎner des Blessures. prÉsenT Manuel d’insTrucTions • Si vous glissez, trébuchez et/ou tomber quand vous utilisez conTienT des renseigneMenTs iMporTanTs des outils pneumatiques, vous risquez des blessures graves ou pour la sÉcuriTÉ.
  • Page 7: Caractéristiques

    MT2880 Rectifieuse Droite .50 CV caracTÉrisTiQues • Moteur de haute performance ½ CV pour plus de puissance et une longévité accrue • Régulateur d'arrêt guidé pour une performance plus versatile dans tous les type de travaux • Commande de levier de sécurité super confortable afin de prévenir les démarrages accidentels.
