- Page 1 THROTTLE ADD-ON Instruction Manual Bedienungsanleitung Mode d‘emploi...
- Page 2 GENERAL ASSEMBLY INFOS PROFILE NUT HEX KEY SET WITH BALL HEAD + EXTENSION OR SIMILAR REQUIRED MTSIM THROTTLE ADD-ON MANUAL...
- Page 3 UNIVERSAL CONNECTOR M8x30 Ø8mm Slot nut M8 BOLT DIMENSIONS AND HOW TO MEASURE THEM [mm] M8x35 M8x25 MTSIM THROTTLE ADD-ON MANUAL...
- Page 4 PROFILE CAP ASSEMBLY MTSIM THROTTLE ADD-ON MANUAL...
- Page 5 [dimensions in mm / different scales] PARTS No extra or spare parts listed! Joystick/Throttle mounting plate as ordered. MTSIM THROTTLE ADD-ON MANUAL...
- Page 6 ASSEMBLY slot nut universal connector M8x30 universal connector M8x30 MTSIM THROTTLE ADD-ON MANUAL...
- Page 7 MTSIM THROTTLE ADD-ON MANUAL...
- Page 8 M8x16 flat head Joystick/Throttle mounting plate as ordered. MTSIM THROTTLE ADD-ON MANUAL...
- Page 9 M8x30 MTSIM THROTTLE ADD-ON MANUAL...
- Page 10 Move the parts to the desired positions by loosening and fastening the universal connectors. 21-03-2022...
- Page 11 WARNING NOTICES CAUTION! Do not clamp your fingers while attaching the throttle add-on. CAUTION! Check before usage if all screws are tightened. DANGER: Contains small parts not suitable for children under 3 years. Only suitable for children over 12 years and adults.
