STEP 5
Attach the Crank Handle
Carriage Bolt
with threads facing up and fasten with
13
Nylock Nut
.
15
Note: There are two holes in the Crank Handle. The hole
closest to the rubber grip will provide a 6" radius for crank-
ing. The other hole will provide an 8" radius, making crank-
ing easier. Use the hole that works best with your model of
lawn mower.
STEP 6
Hang the Lift Arm
on the Carrier by
2
hooking the slotted area of the Lift Arm
over the top bar of the Carrier. Insert
Clevis Pin
through the hole in
17
Carrier and lock by fastening the
Small Hair Pin
to the Clevis Pin.
18
STEP 7
Ready the Wheel Pads
adding Support Rods
9
Note: The Support Rods can be configured to fit
several different tire sizes (see Support Rod Guide
for Tire Sizes on page 18). Use appropriate hole
configuration that works best for your model of
lawn mower.
STEP 8
Slide the Wheel Pads
5
Insert Push Pins
.
16
Note: The Wheel Pads can be moved in or out to fit dif-
ferent mower widths. Use the configuration that works
best with your model of lawn mower.
Assembly Instructions
8
to the Tower
1
by inserting
&
for installation by
5
6
and Large Hair Pins
.
19
&
into the Lift Arm
6
2
Wheel Pad, RH 5
THIS COMPLETES ASSEMBLY.
MoJack EZ Lift
Nylock Nut 15
Carriage Bolt 13
Lift Arm 2
Wheel Pad, RH 5
Support Rod 9
.
Push Pin 16
8
Crank Handle 8
1
Tower
17
Clevis Pin
Lift Arm 2
1
Tower
Top Bar
1
Tower
