RDN 575BT
GB • F • D • I • E • P • SW • PL • GR • CZ/SK • NL
SPecIFIcAtIOnS
General
Reference Supply Voltage
Max Operating Current
Grounding System
Dimensions(WXHXD)
Weight(main unit
FM
Signal Noise Ratio
Residual Noise Sensitivity (S/N=30dB)
Frequency Response (±3dB)
Station Seeking Level
Distortion
Stereo Separation(1KHz)
Antenna Impedance
AM
Residual Noise Sensitivity (S/N=20dB)
Selectivity (±9KHz)
LcD
Screen size
Display resolution
Contrast radio
Brightness
DVD Player
Signal / Noise Ratio
Dynamic Range
Distortion (line out)
Frequency Response (±3dB)
Maximum Output Power
Load Impedance
AUX In
Distortion
Frequency Response (±3dB)
Audio Input Level
Audio
Audio Output Impedance
Audio Output Level
Video
Normal Video Input Level (CVBS)
Video Input Impedance
Video Output Impedance
Video Output Level
environment
Operating Temperature
Storing Temperature
Operating Humidity
Storing Humidity
Note: When the unit is operated extremely, such as operated with
maximum power output for a long time, or the temperature is over 70°C,
it will enter heat protection mode, the volume will be lower automatically.
This is normal.
SPECIFICatIoNS
12V (DC)
10A
Negative ground
178 x 58 x 178 mm
2.15 kg
≥80dB
18dBμV
40Hz~12.5KHz
20~28dBμV
≤1.5%
≥25dB
75Ω
30dBμV
≥50dB
7 inches (16:9)
400 x 240
300
400cd/m
2
90dB
90dB
≤0.1%
20Hz~20KHz
4×75W
4Ω
≤0.5%
20Hz~20KHz
1Vrms
10K Ω
2Vrms (Max)
1.0±0.2V
75Ω
75Ω
1.0±0.2V
-10°C ~ +60°C
-20°C ~ +70°C
45%~80%RH
30%~90%RH
Supported formats:
- USB and SD-card capacity: up to 32GB
- USB or memory file format: FAT32
- Mp3 bit rate (date rate):
- WMA:
- Directory nesting up to a maximum of 8 levels
- Number of albums/folders:
- Number of tracks/titles:
- ID3 tag:
- File name in Unicode UTF8 (maximum length:128 bytes)
Unsupported formates:
- Empty albums:an empty album is an album that does not contain
MP3/WMA files,and is not be shown in the display.
- Unsupported file formats are skipped.For example, Word documents
(.doc) or Mp3 files with extension.dlf are ignored and not played.
- AAC, WMV, PCM audio files
- DRM protected WMA files (.wav,.m4a,.m4p,.mp4,.aac)
- WMA files in Lossless format
Supported MP3 disc format:
- ISO9660,Joliet
- Maximum title number:
- Maximum album number:
- Supported sampling frequencies:
- Supported Bit-rates:
Supported video formats:
- DVD
- MPEG4
- DivX

region code

According to DVD sale region, the whole world is divided into six regions.
A DVD disc can be played back only when its region code is compatible
with that of the player in use.
Region 1: USA, Canada, East Pacific Ocean Islands;
region 2: Japan, West Europe, North Europe, Egypt, South Africa,
Middle East;
Region 3: Taiwan of China, Hong Kong of China, South Korea,
Thailand, Indonesia, South East Asia;
Region 4: Australia, New Zealand, Mid & south America, South Pacific
Ocean Islands/Oceania;
Region 5: Russia, Mongolia, India, Middle Asia, East Europe,
North Korea, North Africa, North West Asia;
Region 6: Chinese Mainland.
cautions of disc using
1) DO NOT use irregular shaped disc
2) Disc Cleaning
Use a dry, soft cloth to wipe the disc from center to edge, only neutral
detergent can be used.
3) When playing a new disc
New disc may have some rough spots around the inner and outer
edges. If such a disc is used, remove these rough spots with a pencil
or ball-point pen, etc.
2
32-320 Kbps and variable bit rate
v9 or earlier
maximum 99
maximum 999
v2.0 or later
512
(depending on file name length)
255
32kHz,44.1kHz,48kHz
32-320Kbps and variable bit rate
