IMPORTANT REMARKS

DIMOEL has the right to modify the product without
previous notice; it also declines any responsibility to
damage or injury to people or things caused by improper
use or wrong installation.
Please read this instruction manual very carefully
before installing and programming your control unit.
• This instruction manual is only for qualified technicians, who
specialize in installations and automations.
• The contents of this instruction manual do not concern the
end user.
• Every programming and/or every maintenance service should
be done only by qualified technicians.
AUTOMATION MUST BE IMPLEMENTED IN COMPLIANCE
WITH THE EUROPEAN REGULATIONS IN FORCE:
EN 60204-1 (Machinery safety electrical equipment of
machines, part 1: general rules)
EN 12445 (Safe use of automated locking devices, test
methods)
EN 12453 (Safe use of automated locking devices,
requirements)
• The installer must provide for a device (es. magnetotermical
switch) ensuring the omnipolar sectioning of the equipment
from the power supply. The standards require a separation of
the contacts of at least 3 mm in each pole (EN 603 35-1).
• To connect flexible or rigid pipes, use pipefittings having the
IP55 insulation level.
• Installation requires mechanical and electrical skills,
therefore it shall be carried out by qualified personnel only,
who can issue the Compliance Certificate concerning the
whole installation (Machine Directive 98/37/EEC, Annex IIA).
• The automated vehicular gates shall comply with the
following rules: EN 12453, EN 12445, EN 12978 as well as
any local rule in force.
• Also the automation upstream electric system shall comply
with the laws and rules in force and be carried out
workmanlike.
• The door thrust force adjustment shall be measured by
means of a proper tool and adjusted according to the max.
limits, which EN 12453 allows.
• We recommend to make use of an emergency button, to be
installed by the automation (connected to the control unit
STOP input) so that the gate may be immediately stopped in
case of danger.
• The appliance is not to be used by children or persons with
reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction.
• Children being supervised do not play with the appliance
• The supply cord cannot be replaced. If the cord is damaged
the appliance sholud be scrapped.

DECLARATION OF CONFORMITY

DIMOEL declares that the components included in
the kit are in conformity with the provisions of the
following EC directives:
2006/95/CEE electrical safety
93/68/CEE electromagnetic compatibility
98/37/CEE machine directive
99/05/EEC radio directive
and with the standards referenced here below:
2006/95/CEE
EN 60335-1
MOOV-B400
EN 60335-2-103
EN 60335-1
CITY7
EN 60335-2-103
MR1 EN 60335-1
TRC-4 DM
EN 60335-1
RIF50
/
EGG220
EN 60598-2-1
Note: Declares that the above mentioned devices may not be
operated until the machine (automated gate) is identified, CE-
labeled, and declared to be compliant to the specifications of
Directive 89/392/EEC and following modifications.
The person in charge for the machine start-up must provide the
following records:
• Technical specification paper
• Declaration of conformity
• CE-labeling
• Testing record
• Maintenance record
• Operation manual and directions
COLLADO VILLALBA (Madrid) 22/05/2001
DIMOEL, legal representative
Antonio Marano
25
93/68/CEE 99/05/EEC
EN 61000-2-3
EN 61000-3-3
/
EN 55014-1
EN 55014-2
EN 61000-6-2
EN 61000-6-3 /
EN 50336
/ EN 301 489-3
EN 301489-3
/ EN 300220-2
V2-1-2
EN 50082-1
/
EN 50082-2
EN 50082-1
/
EN 50082-2
