Power
Zone bypass switches can
be set to ON position to
Versillum Light
keep light output at 100%
Dimmer
Zone 1 AC inputs also
supply the Versillum
Light Dimmer
controller part
If the fixture has an earth
connection, connect it
directly to the electrical
distribution panel.
Symbol
Meaning
The fixture has an earth
connection or no earth connection
(double square symbol means
double insulation)
Formulas
Determine the PF (Power Factor) using this formula:
Determine how many lamps to use on each Zone
output using this formula:
Versillum Light Dimmer 0-10V inputs from
Master Controller with light programs
With one source of 0-10V for two Zones
Set the DIP switch #6 to "ON" position (See Note 2)
Versillum Light
Dimmer
10m max.
BK
See Note 1
RD
OR
With two independant Zone inputs
Versillum Light
Dimmer
10m max.
BK
RD
RD
See Note 1
BK
10m max.
See Note 1
Zone bypass switches have to be set to OFF position to use
the Versillum Light Dimer in normal operating mode. Factory
default setting is the OFF position.
L1
N/L2
N/L2
From electrical
distribution panel
Breaker 1 max: 15Amps
in series with a voltage
interrupter
Power Factor (PF) =
Number of Lamps per Zone =
When there are multiple Versillum Light Dimmers for one 0-10V Master Controller Output,
connect Versillum Light Dimmer inputs in daisy chain on Zone 1 (0-10V) inputs
0-10V Master
Controller Output
+
0-10V
-
Multiple Versillum Light Dimmer Dry contact output 24Vdc, 100mA max.
0-10V Master
Controller Outputs
Zone 2
Note 1: 1 x shielded
+
0-10V
-
twisted pairs, 18 AWG
(min), 600V, 90C (min)
Note 2: Versillum
Zone 1
Light Dimmer will
+
0-10V
internally merge it's
-
two 0-10V inputs to
control simultaneously
Zone 1 and Zone 2
outputs.
Versillum Light Dimmer Wiring Diagram
L1 N/L2
L1
From electrical
distribution panel
Breaker 2 max: 15Amps
in series with a voltage
interrupter
Lamp Power (watts)
Lamp Voltage (V) * Lamp Current (A)
Power Output Amperage (A)
Lamp Current (A)
Multiple Versillum Light Dimmers 0-10V inputs from Master
Controller with light programs
Versillum Light
Dimmer 4
BK
See Note 1
RD
Set the DIP switch #6 to "ON" position (See Note 2)
One Versillum Light Dimmer 0-10V input draws 2 mA. Make sure that the 0-10V Master
Controller Output can supply multiple Versillum Light Dimmers in parallel.
Versillum Light
Dimmer
45m max.
See Note 1
PARAMETERS
ZONE 1
WAVEFORM
ZONE 2
WAVEFORM
MERGE MANUAL CONTROL
MERGE 0-10V INPUTS ON ZONE 1
COLOR
RED
BLACK
Safety Ratings
INPUTS :
SUPPLY INPUT:
• 100-120/220-240Vac ±10%,
50-60Hz,1/2 phase(s)
• 0-10V INPUT (Zone 1, 2): 0-10V,
2mA max
OUTPUTS:
• DRY CONTACT SCENARIO
IMPULSE: 24Vdc max, 100mA max
POWER OUTPUT (Zone 1, 2):
• 100-120/220-240Vac 8.33Amps max
• 100-120Vac, 1000VA, PF ≥ 0.5
(incandescent, CFL, LED)
• 220-240Vac, 2000VA, PF≥ 0.5
(incandescent, CFL, LED)
Operating Temperature: -5 to 45°C
(23 to 113°F)
Formula Example
Lamp details: Voltage: 120V,
N/L2
L1
9 watts and 100mA
Power Output Amperage available:
8.33A on 100-120V or on 220-240V
(Max: 1000VA)
PF =
Number
of Lamps =
per Zone
Round off the decimal point
to get a total of 83 lamps.
Versillum Light
Dimmer 1
See Note 1
10m max.
External Controller
To activate the Dry Contact
Dry
In
Scenario Impulse Output,
RD
contact
Out
Press and hold the
BK
input
"Scenario" button for at
least 2 seconds.
DIP SWITCH POSITION
1
2
3
4
L
ON
OFF
T
OFF
ON
C
ON
ON
L
ON
OFF
T
OFF
ON
C
ON
ON
ON
CODE
RD
BK
9 watts
= 0.75
120V * 0.1A
8.33A
= 83.3
0.1A
0-10V Master
Controller Output
RD
+
0-10V
-
BK
5
6
7
8
9
10
ON
