Micro 800 Conductivity/TDS/Salinity Operating Instructions
Getting Started/Connections
After installing (2) AA batteries and/or connecting
the optional 110/220 VAC power supply, connect
the desired sensors to the corresponding ports.
BNC: pH, mV/ORP
or Ion Selective
ATC/Con: 6-Pin ATC
/Conductivity or ATC
A/C Power
Adapter
12mm and 16mm probes can utilise the probe
holder to attach one or more sensors to a beaker
and to the instrument as needed. The stand can be
extended as shown above or used for wall-mounting.

Keypad Functions

Press once to power ON in the mode that was
previously used. Press again to turn backlight on for
one minute or off. Hold for 3 seconds to power OFF.
Toggle between measurement and calibration modes.
In SETUP mode, BACK serves to return to the previous
menu option or setting.
Confirm calibration values in CAL mode.
Confirm selections in SETUP mode.
Freeze or release the measured reading.
Customise instrument settings and preferences.
(See also Setup Programs).
Toggle between available measurement types.
Save measurement into memory. Increase value
or scroll up in SETUP or manual calibration.
Recall saved values from memory. Decrease value
or scroll down in SETUP or manual calibration.
Send output data to printer or computer.
2
Setup Programs
To access the settings below, press SETUP. Up/down
arrows will display the available options. Press
ENTER to accept the desired setting, or BACK
to return to the previous option and/or exit.
Configuration Options
• Ready indicator ON/OFF/
or Automatic HOLD when stable.
• Choose ºCelsius or ºFahrenheit.
Conductivity Cell Options
• Cell Constant. Choose (0.10/1.00/10.0)
• Temperature Coefficient.
Adjust from 0.00 - 10.0 %/ºC.
• Total Dissolved Solids Factor.
Adjust from (0.00 - 1.00).
• Normalisation Temperature.
Choose (15.0/20.0/25.0/30.0 °C).
• Choose Single-Point Calibration (SPC) to
Output (USB or
RS232 - PC or Printer
apply a single calibration value across all
Communication)
ranges or Multi-Point Calibration (MPC)
to calibrate individual range(s).
• Choose Automatic Calibration
Standards or Manual Adjustment.
Select Calibration Due Reminder
• Set number of days from 0-60 for desired parameter.
View Calibration Data
(for the parameter being measured)
• Press ENTER to view each point that is
calibrated with the associated calibration range.
View Electrode Data
(for the parameter being measured)
• Press ENTER to view the electrode efficiency
of each point that is calibrated with the
associated calibration range.
System Settings
• Data Logging:
MANUAL upon key press only TIMED interval.
Choose (SEC/MIN/HOUR) interval.
• Automatic shut off after 10 minutes.
Choose ON or OFF.
• Clock Settings:
Date: Choose USA (MM/DD/YYYY)
or Euro (DD/MM/YYYY).
Time: Choose (24HR or 12HR).
If 12HR, choose AM or PM.
