INITIAL INSTALLATION
2. Determine mounting method to use.
A. Standard mount
B. Angle mount
Note: Flushmount and closemount options are not
available for this fan.
IMPORTANT: If using the angle mount, ensure the
ceiling angle is not steeper than 19°.
*Helpful Hint: Downrod-style mounting is best
suited for ceilings 8 ft. high or higher. For taller
ceilings you may want to use a longer downrod
(sold separately). Angle-style mounting is best
suited for angled or vaulted ceilings. A longer
downrod is sometimes necessary to ensure proper
blade clearance.
Check to make sure blades (G) will be at least
3.
30 in. from any obstruction and at least 7 ft. above
the floor.
4. Partially loosen two canopy mounting screws (F)
in slotted holes of canopy (B). Remove the other
two canopy mounting screws (F) and star
washers (T) --save for later use. Twist canopy (B)
and remove mounting bracket (C).
2
A
19° max.
B
3
4
F
T
6
30 in.
min.
G
7 ft.
min.
C
F
T
B
