LOADING PELLETS:
With the bolt back and BBs removed from the
magazine (See "TO EMPTY MAGAZINE," Page 10), advance the bolt for-
ward until the magnetic tip is visibly even with the rear edge of the pellet
loading port; lower the muzzle and load a pellet, solid end forward
(No. 7). Push the bolt handle fully forward and the pellet is chambered in
the firing position.
IMPORTANT:
Do not allow a pellet to fall into the rear of the loading
port and become jammed in the BB feed hole. If this occurs, have a
qualified gunsmith remove the left receiver and clear the loading port or
return gun to Daisy.
IMPORTANT:
Care must be exercised when shooting pellets while the
magazine contains BBs. Loading a BB and pellet at the same time may
result in a jammed or obstructed barrel.
BB MAGAZINE
CARGADOR DE BALINES BB
TROMBONE DE BB
PUSH DOOR DOWN TO OPEN
EMPUJE LA PUERTA HACIA ABAJO PARA ABRIRLA
PORTE DE POUSSEE EN BAS POUR OUVRIR
NO. 5
ABERTURA DE CARGA
FENÊTRE DE CHARGEMENT
RIGHT
CORRECTO
MAGNETIC TIP
OUI
PUNTA MAGNÉTICA
BOUT AIMANTÉ
WRONG
INCORRECTO
NON
NO. 6
Step 4. LOAD (PowerLine 22X, 22SGT, 22S)
LOADING PELLETS:
With the bolt back lower the muzzle and load a
pellet, solid end forward (No. 7). Push the bolt handle fully forward and
the pellet is chambered in the firing position.
MAGNETIC TIP
PUNTA MAGNÉTICA
BOUT AIMANTÉ
PELLET
PERDIGÓN
(EL EXTREMO SÓLIDO DEBE IR HACIA DELANTE)
PLOMB
(EXTRÉMITÉ PLEINE EN PREMIER)
NO. 7
LOADING DOOR
PUERTA DE CARGA
VOLET DE CHARGEMENT
LOADING PORT
BB
BALLES BB
LOADING PORT
ABERTURA DE CARGA
FENÊTRE DE CHARGEMENT
(SOLID END FORWARD)
8
Step 5.
CLOSE BOLT
Close bolt by pushing fully forward on bolt handle to chamber either a
BB or pellet and lock the bolt.
CAUTION:
The gun is now loaded and ready to fire.
Step 6. AIM AT SAFE TARGET
Aim the gun at a safe target. To be a consistent marksman, use the
correct sight picture each time you fire your gun (No. 8).
gun, loaded or unloaded, at anyone.
CAUTION:
Due to the power of this air gun, use extra caution
in selecting a safe target backstop. Select the proper target and back-
stop based on the ammunition you are shooting. BBs should NEVER be
shot into a pellet trap. Pick targets and backstops that cannot be pene-
trated or that will not cause ricochet because of their hard surface. Use
only targets and traps that are designed for use with high power air guns.
Do not shoot at water.
Blade Front Sight / La hoja la Vista Anterior / La Vue de Devant de lame
Too High
También Alto
También Bajo
Aussi Haut
Fiber Optic Front Sight
La fibra la Vista Anterior Optica / Fibre la Vue de Devant Optique
Too High
También Alto
También Bajo
Aussi Haut
NO. 8
Step 7. TAKE "OFF" TRIGGER SAFETY
When you are certain the target, backstop and surrounding area is safe,
take trigger safety "OFF" by pushing from right to left so that red is
exposed. Your gun is now cocked and ready to shoot. In this condition, it
should be handled with extreme care.
Step 8. FIRE
After making sure the gun is pointed in a safe direction, gently (but firm-
ly) squeeze the trigger. Repeat Steps 1 through 8 to continue shooting,
using the appropriate loading procedure.
completely closed as indicated in Step 5.
CAUTION:
Do not leave your gun pumped for an extended peri-
od of time. This could result in a time delay from the time the trigger is
pulled until the projectile is expelled from the gun. Also, leaving your gun
pumped for more than one hour could result in permanent damage to the
air release valve.
WARNING:
If a BB or pellet does not fire after completing the
operation steps, the gun is jammed. This is a dangerous condition.
CLEARING A JAM (PowerLine 880, 880S, 1880)
Open the bolt and put "ON" trigger safety immediately. If the bolt is not
completely closed, do not try to close it until after opening it by pulling the
bolt handle all the way back. The gun will not fire a projectile when the
bolt is completely open.
Repeat all operations except Step 4 (do not load BB or pellet), pumping
gun up 10 times. If a projectile still does not fire, follow these steps care-
fully:
1. Open bolt.
2. Put trigger safety "ON".
3. Clear barrel by running a cleaning rod through from the muzzle end. Be
careful not to damage the bolt tip by pushing the rod through too hard. Do
not reuse this BB or pellet.
4. Repeat operation steps. Make sure a BB or pellet is fed into firing posi-
tion. If after following the firing procedure the projectile is not fired, return
your gun to Daisy (See "REPAIR OF DAISY GUNS" section).
UNLOAD PELLETS:
The magnetic tip does not extract a pellet. You must
shoot the pellet out if a safe target is available. If a safe target is not avail-
able, open bolt, put trigger safety "ON", insert a cleaning rod in the muzzle
end and push the pellet out of the barrel. Do not allow a pellet to fall into
the rear of the loading port and become jammed in the BB feed hole.
Never point a
Too Low
Just Right
Apenas Correcto
Trop Bas
A la perfection
Too Low
Just Right
Apenas Correcto
Trop Bas
A la perfection
NOTE:
To fire, bolt must be
9
