Options
TurboZone option (on some models)
®
Blasts into every corner to eliminate the
need for soaking and scrubbing of dirty,
baked-on dishes. For your toughest
items, use the TurboZone option with the
®
Pots & Pans cycle. See loading
information.
High Temp
Raises the main wash temperature to
improve cleaning for loads containing
tough, baked-on food.
Sani Rinse
This high temperature option sanitizes
your dishes and glassware in
accordance with NSF International
NSF/ANSI Standard 184 for Residential
Dishwashers. Certified residential
dishwashers are not intended for
licensed food establishments. Only
sanitizing cycles have been designed to
meet the requirements of the NSF/ANSI
184 performance standard for soil
removal and sanitization efficacy. There
is no intention, either directly or
indirectly, that all cycles on a NSF/ANSI
184 certified dishwasher meet the NSF/
ANSI 184 performance standard for soil
removal and sanitization efficacy. The
Sani indicator indicates at the end of the
cycle whether the Sani Rinse option was
successfully completed. If the indicator
does not activate, it is probably due to
the cycle being interrupted.
Heated Dry
Turns the heat element on after the
wash cycle is completed. Use rinse aid
with or without the Heated Dry option
for best drying results. Plastic items are
less likely to deform when loaded in the
top dish rack.
The maximum additional water used for any combination of options is 2.6 gal. (10.0 L).
†
16
Can be selected
What it does
with
Directs all of the cleaning
power of the dishwasher
Pots & Pans
to the TurboZone
Normal Wash
during certain times in the
wash cycle.
Raises the main wash
Pots & Pans temperature from
Normal Wash 105°F (41°C) to 130°F or
135°F (54°C or 57°C).
Increases the main wash
temperature from 105°F
Pots & Pans
(41°C) to 130°F (54°C) and
Normal Wash
the final rinse from 140°F
(60°C) to 156°F (69°C).
Available with Turns the heat element
any cycle except on at the end of the
Quick Rinse wash cycle.
Added time to cycle
Typical
area
®
42
35
55
32
Added
Water
†
Gallons
Max
(Liters)
0 - 3.7
55
(0 - 14.0)
0 - 3.7
45
(0 - 14.0)
0 - 1.8
100
(0 - 7.0)
32 0
