BGS technic 407 Mode D'emploi page 3

SPECIFICATIONS
Model:
Dimensions:
Nosepiece:
Working range: M3-M4-M5-M6
Hex shaft:
Weight:
Recommended drill/driver as of 12V cordless, also
reversible electric and pneumatic drill/driver with
minimum torque 20 Nm.
ATTENTION
Please read and understand this manual before using the product. Observe all safety instructions!
INTENDED USE
This product may only be used to set rivet nuts of sizes M3-M4-M5-M6 as described in this manual. This
product is not intended for commercial or industrial applications, it meant for private use only.
TOOL DESCRIPTION
1 Hexagon drive shaft
2 Housing
3 Threaded mandrel M3-M4-M5-M6
4 Sight window
5 Nosepieces M3-M4-M5-M6
6 Wrench
SAFETY ADVICE
1. For a save use, please comply with the savety instructions of the driving tool that is used tool.
2. Always disconnect the power supply
- before changing attachments
- before changing work piece
- while the equipment is not in use
3. Ensure the work piece is secured.
4. Keep children away from your work area. Never allow inexperiened personel to work with your
equipment and tools without instruction or supervision.
5. Do not wear loose clothing or jewelry, they can be caught in moving parts.
6. In case of any malfunctions, do not use the equipment any more. Have it repaired by a
professional or contact our customer support. Do not try to repair the equipment yourself. .
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Rivet Nut Attachment
BGS 407
Ø 59mm x length 147mm
M3-M4-M5-M6
6,3 mm (1/4")
340g
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
BGS 407
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
