Replacement Parts List - Suburban DYNATRAIL NT-30SP Instructions D'installation

When ordering repair parts from your dealer, a Suburban Service Center, or distributor, always give the following information:
Item
No. Description
1 Cabinet Assembly .....................................................................101874
2 Fastener, Tinnerman (2 Required) ............................................121662
3 Gasket, Bottom Duct Adaptor
(Required Only if Bottom Ducting is used) ................................062164
5 Cabinet Front (NT-30SP) .................................................... 101871DG
Cabinet Front (Nt-34SP) ..................................................... 101873DG
6 Duct Collar (3 Required on Model NT-30SP;
4 Required on Model NT-34SP) ................................................050715
7 Thermostat ................................................................................ 161154
8 Power Supply Harness ..............................................................520322
10 Electrode ...................................................................................231933
12 Burner Access Door ..................................................................030764
13 Gasket, Electrode ......................................................................070163
18 Gasket, Burner Access Door .....................................................070398
19 Combustion Chamber Assembly (NT-30SP and NT-34SP) . 020932BK
21 Limit Switch (NT-30SP ) ............................................................231244
Limit Switch (NT-34SP) .............................................................230496
24 Bushing .....................................................................................070362
25 Screw, #10 x 3/8 (2 Required) ...................................................121252
26 Wire Clamp ...............................................................................060270
27 Splicer .......................................................................................230714
30 Bushing .....................................................................................230218
31 Bracket, Power Supply ..............................................................063248
33 Switch, ON/OFF ........................................................................232351
34 Bracket ......................................................................................063522
35 Module Board ............................................................................520820
38 Insulator, Module Board ............................................................070807
39 Panel, Board Mounting ..............................................................090301
42 Vent Cap and Exhaust Tube Assembly .....................................260573
43 Intake Tube Assembly ...............................................................050906

REPLACEMENT PARTS LIST

Only factory authorized parts are to be used. Do not attempt to repair defective parts.
1. Part Number (Not Item No.)
2. Part Description
3. Model Number, Serial Number, and Date Code of Furnace
4. Number of Parts Required
Part
Number
Item
No. Description
46 Screw, Vent Exhaust Tube ........................................................ 121711
48 Burner Assembly .......................................................................010701
49 Orifice, Main Burner (NT-30SP) ................................................180214
Orifice, Main Burner (NT-34SP) ................................................180222
50 Gasket, Manifold .......................................................................070408
52 Manifold Pipe .............................................................................171468
53 Valve .......................................................................................... 161123
54 Pipe Assembly, Gas Inlet (Includes Item 57) .............................171434
56 Gasket, Gas Inlet Pipe ..............................................................071034
57 Elbow, 90° .................................................................................171428
58 Gasket, Disc Cover ...................................................................070534
59 Disc Cover, Gas Inlet .................................................................062408
60 Gas Fitting .................................................................................170374
61 Wheel, Room Air ....................................................................... 350113
63 Blower Housing Assembly .................................................... 390283BK
65 Microswitch and Paddle Assembly (NT-30SP, NT-34SP) ..........230509
66 Screw #2 - 56 x 5/8 (2 Required) ..............................................121247
68 Nut #2-56 (2 Required) ..............................................................121951
70 Bracket, motor Mount (3 Required) ...........................................062138
72 Gasket, Crossover Tube (2 Required) .......................................070385
73 Crossover Tube .........................................................................050751
75 Motor Assembly (NT-30SP) .......................................................231207
Motor Assembly (NT-34SP) .......................................................231208
76 Gasket, Motor Mount .................................................................070384
77 Housing, Combustion Air Assembly (NT-24SP, NT-30SP) ... 390179BK
Housing, Combustion Air Assembly (NT-34SP) ................... 390410BK
79 Wheel, Combustion Air .............................................................. 350110
81 Gasket, Combustion Air Housing ..............................................070386
82 Housing, Combustion Air (Outside) ...........................................390424
83A Tinnerman .................................................................................121712
7
Part
Number
