User Manual
EN

Monitor Mount Single Flex

1

Safety instructions

The user manual is part of the product and contains important information for cor-
rect use.
• Read the user manual completely and carefully before use.
The user manual must be available for uncertainties and passing the product.
• Keep this user manual.
• Do not modify product and accessories.
• Use product, product parts and accessories only in perfect condition.
• In case of questions, defects, mechanical damage, trouble and other prob-
lems, non-recoverable by the documentation, contact your dealer or producer.
Not suitable for children and persons with physically and/or mentally limited ab-
ilities.
• Secure packaging, small parts and insulation against accidental use.
• Mounting, dismounting, care, storage, transport and disposal may only be car-
ried out by users with basic mechanical knowledge.
• Have maintenance and repair work carried out by qualified personnel only.
• Avoid stresses such as heat and cold, moisture and direct sunlight vibration
and mechanical pressure.
• Place, install and transport product, product parts and accessories in a safe
way.
• When working with burdens, secure yourself and the working place, let a se-
cond person help you.
• Do not install the product to places with direct sunlight or bright light.
This contributes to eye fatigue.
• Do not hold limbs between shear parts during use.
Moving product parts can pinch or squeeze limbs.
• Keep enough space around product and to the whole system to ensure proper
ventilation and mobility.
• Compare the specifications of all products used.
The specifications of all used products must match or be within the specified ran-
ge.
The supporting surfaces must be able to safely withstand the weight of the mount
and the equipment attached to it.
• Use the mounting screws provided.
• Do not over-tighten the screws.
Threads can be damaged.
2 Description and Function
2.1 Product
The product is a tiltable, rotatable and swivelling table monitor mount for attaching
screens up to 8 kg.
2.2 Scope of Delivery
See Tab. 1.
○ Arm piece (A)
○ Stand (B)
○ Screw clamp (C)
○ Monitor mount (D)
○ Cable gland (E)
○ Cable gland (F)
○ Cover (G)
○ Screw (H)
○ Fixing screw (I)
2.3 Required Tools
See Tab. 2.
○ Philips screwdriver (1)
2.4 Specifications
Item No.
Screen size
Load capacity
Distance between threaded holes according
to VESA standard (vertical x horizontal)
Dimensions (width x depth x height) / Weight
Tilt range
Swivel range
Rotation range
Subject to change without notice.
Model similar.
○ Allen key 4 mm (J)
○ Allen key 6 mm (K)
○ M4x12 (M-A)
○ M4x16 (M-B)
○ M5x12 (M-C)
○ M5x16 (M-D)
○ Washer D5 (M-E)
○ Spacer (M-F)
○ User Manual
58528
43 - 81 cm (17 - 32")
8 kg
75x75, 100x100
114 x 454 x 498 mm / 2.54 kg
-45° ~ +45°
-90° ~ +90°
-180° ~ +180°
3 Intended Use
We do not permit using the device in other ways like described in
chapter „Description and Function" or in the „Safety Instructions". Use
the product only in dry interior rooms. Not attending to these
regulations and safety instructions might cause fatal accidents, injuries, and
damages to persons and property.
4

Preparation

• Check the scope of delivery for completeness and integrity.
5 Mounting
5.1 Inserting the cover into the stand
See Fig 1.
5.2 Mounting the screw clamp on the stand and attaching
it to the table top
See Fig. 2.
5.3 Mounting the arm piece on the stand and attaching
the cable glands
See Fig. 3.
5.4 Attaching the monitor mount to the screen
See Fig. 4.
5.5 Installing and securing the monitor mount
See Fig. 5 and Fig. 6.
This step must be carried out by 2 people!
5.6 Using the cable glands
See Fig. 7 and Fig. 8.
5.7 Adjusting the screen
See Fig. 9.
6 Maintenance, Care, Storage and Transport
• Let maintenance and repair work only be carried out by qualified personnel.
• Protect the joints from dirt and grease them regularly with light machine oil.
• Only use a dry and soft cloth for cleaning.
Use caution when cleaning to avoid scratches. In case of heavy soiling, the clea-
ning cloth can be slightly moistened with water.
• Do not use detergents or chemicals.
• Regularly check the tightness of product/screws.
Fixing holes can remain visible when the product is removed. After prolonged use,
a stain may remain on the underground.
• Store the product out the reach of children and in a dry and dust-protected am-
bience when not in use.
• Keep and use the original packaging for transport.
7

Disposal instructions

This product does not belong into the household waste. At the end of its working
life, give it back to the manufacturer, the sales outlet or established for this pur-
pose, public collection points for free. Details of disposal are regulated by the
respective country's law. Recyclables are into the recycle circuit, in order to gain
new raw materials. The following recyclable materials are collected in municipal
collection: Waste glass, plastics, scrap metal, sheets and much more. With this
type of scrap usage you are making an important contribution to protecting our
environment.
8 Warranty
Detailed warranty conditions on www.mygoobay.com.
9 Symbols used
For indoor use only
- 10 -
IEC 60417- 5957
