Audible Alarm (internal to the inverter) — When the Audible Alarm makes
a buzzing sound, the inverter senses a low battery condition. The user
should reduce the AC load, charge the battery, and check the DC cable for
excessive losses.
REAR PANEL
Positive (+)
Terminal
[Red]
•
Positive Terminal — Positive (+) DC Input (Red)
•
Negative Terminal — Negative (−) DC Input (Black)
•
Cooling Fan — High-speed and load controlled
•
Ground Terminal — For attaching an insulated safety ground wire. This
safety wire is for protecting personnel if there is an unlikely failure in either
the cabling or enclosure insulation.
Wagan Tech and wagan.com are trademarks used by Wagan Corporation.
User's Manual—Read before using this equipment
Cooling Fan
©2015 Wagan Corporation. All Rights Reserved.
Negative (−)
Terminal
[Black]
Ground
Terminal
5
