Current EVOLVE Guide D'installation

Evolve
™
(EAL)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Save these instructions for future use.
Risk of electrical shock. Disconnect power before servicing
or installing product.
Risk of injury or damage. Unit will fall if not installed
properly. Follow installation instructions.
Risk of injury. Wear safety glasses and gloves during
installation and servicing.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
LED Area Light
WARNING
WARNING
CAUTION
.
This luminaire is designed for outdoor lighting service,
and should not be used indoors.
Install and maintain according to this guide.
Mount to a vertical pole with LEDs facing down, or
aimed up to 45° upward with a Knuckle slipfitter.
SPECIFICATIONS
Weight: <30 lbs (13.6 kg)
Effective Projected Area (EPA)
Mounting
Knuckle Slipfitter 'S', 45° aim
Knuckle Slipfitter 'S', horizontal
Internal Slipfitter
Decorative Arm
IP Rating: Optical 65, Electrical Enclosure:
UL 1598 Wet Location Rated
Installation Guide
GEH-6049
Sq. Ft. Sq. M.
2.45 0.23
0.73 0.07
0.54 0.05
0.63 0.06
