ZEPHYRONLINE.COM
Mounting the Hood
12. ZRV : Lilft glass canopy and place on top of hood body, secure glass canopy to hood body by (4)
3/16 x 1/4 screws. Hand tighten screws.
13.
* If using hood in recirculating mode you must secure the air diverter plate onto wall before
installing duct work and duct covers. You will also need to install charcoal filters and brackets.
Turn to page 18 for more details.
Ductless Recirculation
Ductless recirculation is intended for applications where an exhaust duct work is not possible to be
installed. When converted, the hood functions as a recirculating hood rather than an exhaust hood.
Fumes and exhaust from cooking are drawn and filtered by a set of optional charcoal filters. The air is
then purified and re-circulated back within the home.
We recommend to ALWAYS exhaust air outside of the home by employing existing or installing new
duct work, if possible. The hood is most effective and efficient as an exhaust hood. Only when the
exhaust option is not possible should you recourse to converting the hood into a recirculating hood.
When converted to be a recirculating hood, a set of charcoal filters are required on top of its standard
Metal Filter set. Order according to its part number below. The standard mesh filters are intended to
capture residue from cooking, and the optional charcoal filters help to purify fumes exhausted from
cooking for recirculation.
Recirculating Kit Installation (required if no ducting is used)
For detailed installation instructions, please refer to the manual included with the recirculating kit.
The kit includes the charcoal filters, charcoal filter brackets, and air diverter plate.
Recirculating Kit
Hood Model
ZAN
ZSA
ZRV
ZRO
Savona, Anzio, Ravenna, Roma Use, Care, and Installation Guide
Part Number
ZRC-01AN
ZRC-00SV
ZRC-00RV
ZRC-01RO
Installation Instructions
Charcoal Filter
Filters in
Replacement Part
Package
2
2
2
2
Number
Z0F-C091
Z0F-C002
Z0F-C002
Z0F-C002
Quantity to
Order
2
2
2
2
17
