Only use original genuine DAISHIN parts. Other parts may be dangerous for your health and
If some vibration occur or/and If you feel vibrations in the handlebar, check the blade or made
it checked by your dealer. Vibrations may cause loosening of the bolt and nuts and may crack
L
UBRICATION:
 Lubricate the control pivot axle, blade brake axle and wires with light oil.
 Grease the front wheel axle (A figure 7) with grease NLGI N°2.
A
IR FILTER:
Dismount the air filter by sliding the key (1 figure 9) backward and pulling the cover.
Pull the paper cartridge and the foam (Figure 10 & 11)
Foam filter :
Clean the foam with water and soap. Dry the foam, and oil slightly with engine oil, press the oil in
excess without twisting.
Paper:
Blow the cartrige "C"with low air pressure from the inside to the outside, oposite to the normal air flow.
Change the cartridge if it is too dusty or after five cleaning.
Reassemble througly the air filter system
E
NGINE:
Refer to engine manual deliver with the machine.
Engine oil level:
Unscrew the dipstick (1, figure 12) Clean it and put it on the engine without screwing it. Check the oil level, it
must be on the A & B. Add oil if it is required with gasoline engine oil SAE 10W30 API SF or SG.
DAISHIN SRM180K
for the bystanders and the machine.
the steel of the machine.
Figure 8
Figure 10
Figure 12
Figure 7
Figure 9
Figure 11
Figure 13
