PEERLESS SmartMount Serie Mode D'emploi

Installation and Assembly:
SmartMount
for LCD and Plasma Flat Panel Screens
Product is UL rated for screen size
range and load capacity
Model #
ST670, ST670P, ST670-S, ST670P-S
ST680, ST680P, ST680-S, ST680P-S
Features:
• Screen held only 3" from wall for a discreet installation
• Wall plate design allows for wall acces allowing multiple cable management options
• Universal tilt brackets easily hook onto wall plate for fast installation
• Adjustable up to 15° of forward tilt and up to -5° backward tilt for optimal viewing angle
• One-touch tilt for effortless adjustment
• Pre-tensioned universal tilt bracket allows for tilt angle adjustment in one easy motion.
• Easy grip handle locks the screen position into place
• Optional IncreLok feature offers fixed tilts at -5°, 0°, 5°, 10° and 15° increments
• Includes Sorted-For-You™ fastener pack for installation to wood studs, concrete, and cinder block
• Optional horizontal adjustment of up to 8" (depending on screen model) for perfect screen placement
• Available in Black or Silver
Universal Tilt Wall Mount
®
per chart below
Screen Size Range Max. UL Load Capacity
42''- 71''
61''- 102''
R
250 lb (113 kg)
350 lb (159 kg)
This product is UL Listed. It must be
installed by a qualified professional
installer.
