3. Two fuses are mounted on the rear of the IEC
connector (both 'Live' and 'Neutral' mains
supply leads are fused). These fuses can be
removed and replaced by hand. ALWAYS replace
the fuse by ones of the correct values shown
below:
For 230V, 50Hz - T1A
For 120V, 60Hz - T1.6A
4. Refit the base and four securing screws.
5. It is advisable to perform a 'PAT' (Portable
Appliance Test) electrical safety test, or
equivalent, before the unit is put back into
operation.
For a comprehensive list of parts required by service
engineers conducting internal repairs, or to
receive a service manual, please contact the
Service Department at;
cpservice@coleparmer.com
Tel: +44 (0)1785 810475
Quote both the model and serial number.
Only spare parts supplied or specified by Cole-Parmer
or its agents should be used. Fitting of non-approved
parts may affect the performance and safety features
designed into the instrument. If in any doubt, please
contact the Service Department of Cole-Parmer or
the point of sale.

Technical Specification

Number of samples
Temperature range
Temperature resolution
Temperature accuracy at 20ºC
Temperature accuracy at 300ºC
Display
Sensor
Ramp rates
Dimensions (WxDxH)
Net weight
Warranty
Cole-Parmer Ltd. warrants this instrument to be
free from defects in material and workmanship,
when used under normal laboratory conditions,
for a period of three (3) years. In the event of a
justified claim Cole-Parmer will replace any defective
component or replace the unit free of charge.
This warranty does NOT apply if damage is caused by
fire, accident, misuse, neglect, incorrect adjustment
or repair, damage caused by incorrect installation,
adaptation, modification, fitting of non-approved
parts or repair by unauthorised personnel.
Cole-Parmer Ltd.
Beacon Road,
Stone, Staffordshire,
ST15 0SA, United Kingdom
Tel: +44 (0)1785 810475
Email: cpservice@coleparmer.com
Web: www.stuart-equipment.com
SMP10
Two
Ambient to 300°C
1°C
±1.0°C
±2.5°C
Three digit LED
PT100
20°C / minute to plateau
2°C / minute to melt
160 x 220 x 170 mm
1.8 Kg
SMP20
Two
Ambient to 300°C
0.1ºC
±1.0°C
±2.5°C
Four digit LED
PT100
20°C / minute to plateau
Between 1 and 10ºC/ min
160 x 220 x 170 mm
1.8 Kg
