Delivery Includes; Ordering Code; Terminal Assignment - Crouzet CTR24L-2511 Notice De Mise En Service

Ambient temperature:
-20 ... +65 °C at 10 ... 26 V DC
-20 ... +55 °C at >26 ... 30 V DC
Storage temperature:
Altitude:
EMC:
Emission
Immunity
Housing:
For front panel mounting: 48 x 24 mm
acc. to DIN 43700, RAL7021, dark grey
Weight:
Protection:
Cleaning:
The front of the units is to be cleaned only with a
soft wet (water !) cloth.

5. Terminal assignment

1 10 ... 30 V DC
2 0 V GND
3 INP A
4 INP B (Tachometer: n.c.)
5 SET/RESET (Tachometer: n.c.)
8. Dimensions:
48
CTR24L
8
–25 ... +70 °C
to 2000 m
EN 55 011 Class B
EN 61 000-6-2
appr. 50 g
IP 65 (front)

6. Delivery includes:

1 Digital display
1 Panel mounting clip
1 Seal
1 Multilingual operating instructions

7. Ordering code:

87.623.570
Panel cut-out:
22.2+0,3 x 45+0,6 mm
