Safety Guidelines; Technical Data; Options; Assembly - resideo Braukmann FF40 Instructions D'installation

1

Safety Guidelines

1. Follow the installation instructions.
2. Use the appliance
• according to its intended use
• in good condition
• with due regard to safety and risk of danger.
3. Note that the appliance is exclusively for use in the
applications detailed in these installation instructions
(see 2 Technical Data). Any other use will not be
considered to comply with requirements and would
invalidate the warranty.
4. Please take note that any assembly, commissioning,
servicing and adjustment work may only be carried
out by authorized persons.
5. Immediately rectify any malfunctions which may
influence safety.
2

Technical Data

Media
Medium:
Connections/Sizes
Connection sizes:
Pressure values
Max. operating pressure:
Operating temperatures
Max. operating temperature
medium:
Specifications
Installation position:
3

Options

For Options visit homecomfort.resideo.com/europe
4

Assembly

4.1 Installation Guidelines
• Install in horizontal pipework with filter bowl
downwards
– This position ensures optimum filter efficiency
• Install shut-off valves before and after the filter
• Ensure good access
– Degree of contamination can be easily seen with
clear filter bowl
– Simplifies maintenance and inspection
• The installation location should be protected against
frost
• Do not install in places where there is strong sunlight
• In order to avoid flooding, it is recommended to
arrange a permanent, professionally dimensioned
wastewater connection
MU1H-1142GE23 R0220
Water
3
/ " female,
4
3
1" male with / " - 1" adapter
4
6 bar
45 °C
Horizontal with filter bowl
downwards
GB
• These filters are armatures which need to be
maintained regularly
4.2 Assembly instructions
1. Thoroughly flush pipework
2. Install filter
• Note flow direction (indicated by arrow)
• Install without tension or bending stresses
3. The appliance is ready for use
5

Maintenance

In order to comply with EN 806-5, water fixtures must
be inspected and serviced on an annual basis.
As all maintenance work must be carried out by an
installation company, it is recommended that a
servicing contract should be taken out.
If necessary, the outside surface of the filter can be cleaned.
Use only cold, clear drinking water to clean the surfaces.
Any other cleansers cause damage to the plastic
components!
In accordance with EN 806-5, the following measures must
be taken:
5.1 Inspection
Regular inspection of filter insert - approx. every 4
month.
• Replace if contamonation is high!
5.2 Maintenance
5.2.1 Filter bowl
1. Close shut-off valve on inlet and outlet
2. Release pressure on outlet side
3. Unscrew filter bowl
4. Remove filter cartridge
5. Insert filter cartridge in new filter bowl
6. Screw filter bowl in place
7. Open shut-off valve on inlet
8. Slowly open shut-off valve on outlet
3
