5.2.3 Assembly on a flush-mounted socket (with the installation kit W3 INST-KIT1,
)
Art. No. 88148
With the aid of the W3 INST-KIT, the camera can be installed onto standard flush-mounted sockets.
13 14
Description of components
11
() Fixing screws for securing camera base to panel (3)
(3) Panel for attachment to the flush-mounted socket
(4) Panel for attachment of camera
NOTE: Screws for attachment to the flush-mounted socket
Easy-Installation cable
. Connect plug socket (camera side) and plug (cable side),
. Adjust the camera angle. The panel nut (3) must be
W3 INST-KIT1 assembly kit is installed with the camera on
the flush-mounted socket.
Wall
. Using the screws, secure the camera on the W3 INST-KIT
Flush-mounted
socket
. Re-tighten the 3 screws that hold the neck.
NOTE: Flush-mounted socket, screws for the kit assembly
are not included.
slightly loosen the 3 screws that hold the neck (0) (but do
not undo them completely!), so that the body of the camera
can move.
inserted in the hole in the camera assembly panel (9).
assembly kit.
panel and screws and rawl plugs for wall
attachment are not included.
