Parts List - PEERLESS Mounts FPEPM-05 Guide D'installation

Before you begin, make sure all parts shown are included with your product.

Parts List

Description
A support column
B concrete expansion anchor
C adapter box
D tilt plate
E 1" socket screw
F 1/4-20 x 3/4" socket cap screw
G column cap
H M10 x 16mm socket screw
I split lock washer
K nylock nut
L washer
Parts may appear slightly different than illustrated.
B
A
H
E F
I
FPEPM-05
FPEPM-06
FPEPM-07
FPEPM-08
Qty. Part #
1 see chart
8 5M9-381-H03
1 061-7380
1
061-7351
4 520-5035
6 520-5034
1 590-1336
4 520-5013
4 540-5001
6 530-5007
6 540-5014
G
K
3 of 24
Support Column (A)
Model # Part #
FPEPM-05 061-7276
FPEPM-06 061-7277
FPEPM-07 061-7278
FPEPM-08 061-7279
C
L
ISSUED: 11-10-10 SHEET #: 061-9060-1
D
