EN
LED TABLE LIGHT with QI 2.0
INSTRUCTION MANUAL
Thank you for choosing the LED TABLE LIGHT with QI 2.0. Your lamp has
several functions. Please make yourself familiar with the functions and read the
instructions carefully before using your table lamp.
Technical data:
Name: LED TABLE LAMP with QI 2.0
Model: 20153,20154
Weight: 880 g
Color: black or white
Dimensions: (l, w, h in mm) 180*180*340
Packaging dimensions: (l, w, h in mm) 220*220*385
Color temperature range: 2700-5000 K
luminous flux: 380 lm
brightness range: 1 %-100 %
Color rendering index: Ra>90
Input power: 24 W (LED 7 W / wireless charging 10 W / USB 5 W)
Nominal values of the adapter: 100-240 V 50/60 Hz
rated current: 1 A
Adapter rated power: 12 V 2 A
Wireless charger: Mobile device compatible with Qi charging standard (Qi1.2.4
EPP compliant)
Output voltage Max. 9 V
Output current Max. 1 A
USB output: 5 V 1 A
Service life: approx. 25,000 hours
Scope of delivery
Lamp
Power supply cable
EXPLANATION OF THE PRODUCT
PROPERTIES
1. infrared on/off switch
2. indirect LED light
3. lampshade
4. wireless charging pad
5. USB charging port
6. touch key for color temperature
7. touch key for brightness
Intended use
This device is only intended for the above
mentioned use. Any other or additional use is considered improper.
CE Declaration of Conformity
Mobiset GmbH hereby declares that this product is in conformity with the
EU-Konformitätserklärung
basic requirements of the applicable European directives.
DECLARATION OF CONFIRMITY
Mobiset GmbH
Rösratherstr. 333
D-51107 Köln
Tel.: 0221 – 98 95 20
erklärt hiermit, dass das nachfolgend aufgeführte Produkt bei bestimmungsgemäßer Verwendung den
grundlegenden Anforderungen folgender Richtlinien entsprechen:
Declares herewith, that the products designated below comply with the relevant fundamental
requirements of the following EG directives:
EMC 2014/30/EU
LVD 2014/35/EU
General notes
ROHS 2011/65/EU and its amendment Directive (EU) 2015/863
Directive 2009/125/EG Commission Regulation (EU) 2019/1782
Produkt / product: Teleskop Ventilator / teleskopic fan
Typ/Type: 20227
Folgende Normen wurden angewendet: following Standards are used:
EN 55014-1:2017; EN 55014-2:2015
EN 61000-3-2:2014; EN 61000-3-3:2013
Copyright
IEC 60335-1:2010+A1:2013+A2:2016
IEC 60335-2-23:2015
IEC62321-4-2013+A1:2017; IEC 62321-5-2013
IEC 62321-7-2-2017; IEC 62321-6-2015
IEC 62321-8-2017
This document is protected by copyright. Any duplication or reprinting, in whole
Köln, Cologne
20.05.2020
or in part, as well as the reproduction of the illustrations, even in modified form, is
____________________________
Dietmar Jung CEO / Geschäftsführer
prohibited. only with the written consent of the manufacturer.
Notes on environmental protection
The packaging materials used are recyclable. Dispose of no longer needed
Packaging materials according to local regulations.
This product must not be disposed of with normal household waste within
the European Union. Dispose of the device via the municipal collection
points.
OPERATION OF THE LAMP
1 ) Connect the power supply cable.
2 ) Switch on the lamp by moving your hand over the
lampshade.
3 ) Color temperature / brightness and on/off switching
•
Select one of 5 light colors with the color temperature button
•
Select one of 4 brightness levels with the brightness button.
•
Touch these two buttons simultaneously and turn off the light. When the light
is off, touch either button to turn the light back on.
brightnes s
colors
4 ) Wireless charging
Place your wireless chargeable smartphone
on the glass of the wireless charging pad to
start charging.
5 ) Load a second device
Connect a charging cable to the USB
charging port to charge a device.
You can charge one device wirelessly and
simultaneously charge a second device
with one cable
CAUTION:
Read all instructions and warnings carefully before using this product.
•
Inspect the device for visible external damage before use.
•
Do not place the table lamp in a high temperature environment.
•
Keep the table lamp away from naked flames or an excessively hot environ-
ment.
•
Do not expose the table lamp to moisture and never immerse the table lamp
in liquid.
•
Make sure that the table lamp is always dry.
•
Never attempt to charge the table lamp using any method or connection
other than the supplied charging cable.
•
Do not disassemble this table lamp or attempt to repair it or place it in any
way to modify.
•
Handle the table lamp carefully. Take care not to fall, bump, scratch or other-
wise bump into the lamp. If the table lamp is damaged, such as dents, holes,
cracks, deformation or rust, it should not be used.
•
If you notice an unusual smell, high temperature (low temperature during
normal use), discoloration or unusual changes in shape it may no longer be
used.
•
Persons who are not able to operate the lamp safely due to their physical,
mental or motor skills may only use the lamp under the supervision or inst-
ruction of a responsible person.
•
Allow children to use the lamp only under supervision.
Simultaneousl y Press
ON/OFF
Wireless charging
