10. Wiring diagram
«i»
[i]
Light on : door open
or fault
11. Detail of the RDX8 switch wiring on an external relay in area 3G/3D
Red
Grey
White
Datasheet of RDX8 switch
White
Blue
Red
Black
RDX8
Grey
Orange
24VAC/DC
T11
T21
T12
km1
km2
KM1 and KM2 are optionnal
M
power contactors.
IMPORTANT :
Check the dip-switch status (N/SR)
at the back of the device
White
Blue
Red
Black
RDX8
Grey
Orange
250VAC max
13
23
33
41
A1
C
AWAX26XXL-EEX3
13
23
33
41
14
24
34
42
T22 A2
V
14
24
34
42
KM2
L
KM1
Safety contacts : 13-14, 23-24, 33-34
Auxiliary contact : 41-42
Black
Orange
Green
Blue
White
Red
Black
RDX8
Grey
Orange
BP
KM1
KM2
