Section 6. Troubleshooting and Repair

Zodiac strongly recommends that you call a licensed and qualified service professional in to perform any repairs
on the filter/pump system. To locate an independent service company, check your local yellow pages or visit: www.
zodiacpoolsystems.com.
6.1

Troubleshooting

Symptom
The cleaning/circulating system is
not operating correctly.
Bubbles present in the filtration
pump basket.
Air leaks are still present.
There is no air in the system, but
the pressure is still low.
There is no debris blocking the
impeller and the pressure is still
low.
The pump is leaking water between
the motor and pump body.
The pump gets hot and shuts off
periodically.
|
Polaris PB4-60 Booster Pump
®
Verify that skimmer baskets, pump basket and other screens are clean. Clean as
necessary.
Check filter and clean as necessary.
Check valve positions. Adjust as necessary.
NOTE Multiple pieces of equipment operating at one time (for example, waterfalls, spa
jets, and surface returns) may prevent the cleaning system from working properly.
Check the cleaning system manually to ensure that the system is adjusted according to the
manufacturer's recommendations.
Air in system. Check the pool or spa water level to ensure it is at the proper level and
that air is not being drawn into the suction piping. If the water is at normal level, turn off
the pump. Remove the lid and check for debris around the lid o-ring seat or improper
installation of the lid seal, as this either of these conditions will cause air to leak into the
system. Clean the lid o-ring and place on the lid. Hand-tighten the lid to make an air tight
seal. Do not use any tools to tighten the lid. Turn the pump back on.
Check the suction side piping union. While the pump is running, try to tighten the union. If
this does not stop the air leak, turn off the pump. Loosen both unions and slide the pump
out of the way. Remove, clean and re-install both union o-rings on the filtration pump.
Reposition the pump next to the piping and secure the union nuts to the pump. With clean
union o-rings, hand-tightening of the unions should create a seal. If the unions still do not
seal, gently tighten with a large pair of tongue-and-groove pliers.
Do not over-tighten.
It is possible that debris is caught in the pump impeller. The pump impeller moves the
water, and the vanes in the impeller can become blocked with debris. See Section 6.2,
Service Technician Maintenance, 6.2.1, Blocked Impeller, for more information.
The pump impeller is showing signs of normal wear. Have a qualified service technician
check the impeller and replace as necessary.
If the pump is part of a relatively new installation, it could be an electrical problem. Contact
a qualified service technician. Have the technician check for loose electrical connections
and check the voltage at the pump motor while it is in operation. The voltage must be within
10% of the motor's data plate rating. If the voltage is not within 10%, contact a qualified
electrician and/or the local power service provider.
Pump seal is leaking air. Have a qualified service technician replace the seal.
This is caused by a damaged or failed mechanical seal. Replace the seal. See Section 6.2,
Service Technician Maintenance, 6.2.4, Mechanical Seal Replacement.
Ensure that there is adequate room around the motor to circulate air and keep the motor
cool. Have a qualified electrician check for loose connections and check the voltage at the
pump motor while it is in operation. The voltage must be within 10% of the motor's data
plate rating. If the voltage is not within 10%, contact a qualified electrician and/or the local
power service provider.
