DELTA DORE TYDOM 1.0 Guide Rapide page 2

TYDOM 1.0
Connected home box
EN
APPLICATION
www.deltadore.com
3
3.1
ADSL BOX
3.3
1
MAC : 001A25xxxxxx
MAC : 001A25FFFF123456
1 2 3 4 5 6
Contents
A. TYDOM 1.0
Connected home box for application on
DELTA DORE TYDOM smartphone and tablet
B. Mains supply
C. Ethernet cable
D. Installation instructions/
Important product information
E. AC adapter
1 2 3 4 5 6
Description
F.
System status display LED
Connections:
G. Ethernet socket
H. Not used
I. Mains adaptor socket
Button:
J. Configuration/information button
Product association example
Control system
receivers
Alarm
RT 2012 range
INPUT 100-240V~ 50-60 Hz 0,3A
OUTPUT : 5V
-20°C/+70°C
-10°C/+40°C
100 x 100 x 30 mm
The connection quality of the product may be affected by diffe-
rent modifications of the IP architecture on which it operates.
These modifications can be, but are not limited to, a change of
hardware, a software update or configuration, work conducted
on your operator's equipment or any other multimedia equip-
ment such as tablets, smartphones, etc." Android™ and Goo-
gle are registered trademarks of Google Inc. IOS™ is a regis-
tered trademark of Cisco Systems Inc. WiFi is a trademark by
INFO
Wireless Ethernet Compatibility Alliance. Because of changes
in standards and equipment, the characteristics given in the
text and the illustrations in this document are not binding unless
confirmed.
2
C B
2
1 2 3 4 5 6
Installation
3.1 Connect the TYDOM 1.0
according to your installation
3.2 Download the TYDOM application
1. According to the unit:
Log in to Google play or App Store
2. Search for and download
the free "TYDOM" application
3. Activate the WIFI connection of your
smartphone or tablet.
3.3 Configure the TYDOM application
– Note down the last 6 characters of the MAC
address of your TYDOM 1.0.
— Open the TYDOM application.
˜ Enter the 6 characters (upper case letters) in the
"identifier" field then enter your "password" (at
least 8 alphanumeric characters).
™ Press the "Login" button.
š The home screen is displayed.
You are logged in.
1
or
2
Set the receiver to
association wait mode
(refer to the user guide)
Identification
Access code
Set the alarm control unit
to add product mode
(refer to the user guide)
Continue
Set the product to
association wait mode
(refer to the user guide)
1
1.0 A
A
IP 30
B
C
D
C
ADSL
B
BOX
C
Identifier
3
_
Password
_
1 2 3 4 5 6
Information and support
LED System status
Pulsing System accessible locally
green and remotely, user connected
Green on and System accessible locally
steady and remotely
Pulsing System accessible locally, user
orange connected
Orange on System accessible locally
and steady
Red on and No IP address allocated
steady
Diagnostic function
Briefly press the button
(LED displays for 10 seconds)
Flashing
Fixed IP OK
yellow
Flashing
DHCP OK / Upnp OK
blue
Flashing DHCP OK / Upnp Error
blue (2x) Check the Upnp activation on the BOX
Flashing DHCP in progress
blue (3x) Check the DHCP activation on the BOX
3
2
Start
Beep
Continue
1 kWh
0.75
0.5
0.25
0:00 6:00 12:00 18:00 23
Other
thermal products
2
E
3.2
4 5
Connect
Flashing
red
Advanced functions
Press the button for at least 3 seconds
LED
Flashing
magenta
(slowly)
Preferably use the TYDOM application to access this
function.
Press the button for at least 15 seconds
LED
Flashing
magenta (rapidly)
Press the button for at least 30 seconds
LED
System status
Customisation
North bedroom
1
1
Receivers
found
1
On
ON
Off
OFF
TYBOX 137
example
Set the product to
association wait mode
(refer to the user guide)
F
G H I J
ON
No network connection
Check the Ethernet link
Fixed IP -> DHCP
Action
Release the button
(before 15 seconds)
Delete password
Action
Release the button
(before 30 seconds)
RESET
Action
Release the button
Use of DHCP
Password deletion
Association removal
shutter 1
Locate
Pictogram
Rename
change
Continue
