Description

1 Use
A good grinding result is achieved with turning the electrode and slightly pressing it
against the grinding wheel. Pull the electrode out of the housing hole before switching off
the tool.
Excessive pressure will damage the tool and increase the use of grinding wheels; the
grinding performance will decrease.
Grinding of the electrodes is done in two steps:
1.Dull-angled tip (about 70°)
2.Sharp-angled tip (about 15°)
The housing holes in the grinding head are marked accordingly
It is recommended to grind in this way to use the special guiding
characteristics of the housing holes.
2 Motor unit
