Linksys EA-Series

Product Overview

EA6350

Top view
Indicator light—Stays on steadily while power is connected and
•
following a successful Wi-Fi Protected Setup connection. Blinks or
pulses slowly during bootup, during firmware upgrades, and during a
WiFi Protected Setup connection. Blinks quickly when there is a WiFi
Protected Setup error.

Back view

Wi-Fi Protected
Setup button
Reset button
Adjustable Antennas— The included two external antennas are
•
adjustable for best performance.
NOTE
Indicator light
For best performance, position the side antennas vertically at a 90˚
angle as shown in the picture on the left.
Wi-Fi Protected Setup™ button—Press to easily configure wireless
•
security on Wi-Fi Protected Setup-enabled network devices.
USB ports—Connect and share a USB drive or a USB printer
•
Ethernet ports—Connect Ethernet cables to the blue gigabit
•
(10/100/1000) ports and to wired Ethernet network devices.
NOTE
For best performance, use CAT5E or higher rated cables on the
Ethernet ports.
Product Overview
Adjustable Antennas
Internet port
USB port
Ethernet ports
Power port
1
